Features : ventilation FAN
- Capacitor Start & Run Induction Motor
- Motor Copper Winding
- Class F Insulation (155°C)
- Aerodynamic Design moulded blade
- Compact Plastic Body
- Collapsible Louvers
- Aluminium Motor Body
- Optional Grill also available
Features : FRESH AIR FAN
- Capacitor Start & Run Induction Motor
- Copper Winding
- Class F Insulation (155°C)
- Sealed Double Ball Bearings, with P6 tolerance
- Aerodynamic Design moulded blade
- Aluminium Motor Body
- Metallic frame with rubber mounting
- Aluminium Epoxy Powder Coated Body
- Metal Bird protection guard
Also Available
- Reversible fan (2 in 1)
- Fingerproof Guards
- 110, 220V 60Hz Model
- Motor with inbuilt resettable Thermal Protector
| Size | Type | Supply | Speed (RPM) | Input Power (W) | Air Delivery (M3/hr) | Size (A) mm | Size (B) mm |
|---|---|---|---|---|---|---|---|
| 6" (150 mm) | Ventilation Fan | Single Phase, 50Hz | 2250 | 50 | 530 | 235 | 190 |
| 8" (200 mm) | Ventilation Fan | Single Phase, 50Hz | 2200 | 55 | 800 | 300 | 240 |
| 9" (225 mm) | Fresh Air | Single Phase, 50Hz | 1400 | 45 | 750 | 294 | 213 |
| 12" (300 mm) | Fresh Air | Single Phase, 50Hz | 1400 | 60 | 1300 | 395 | 305 |
| 9" (225 mm) | Fresh Air | Single Phase, 50Hz | 2700 | 50 | 900 | 294 | 213 |
| 12" (300 mm) | Fresh Air | Single Phase, 50Hz | 2350 | 70 | 1300 | 395 | 305 |
