Features
- Capacitor Start & Run Induction Motor
- Copper Winding
- Class F Insulation (155°C)
- Sealed Double Ball Bearings, with P6 tolerance
- Aerodynamic Design
- Precisely Balanced Metal Blade
- Aluminium Diecast Hub
- Metal Frame with rubber mounting
- Aluminium epoxy powder coated body
- Metal bird protection guard
Also Available
- Reversible Fan (2 in 1)
- Finger proof Guards
- 110, 220V 60 Hz Model
- Motor with inbuild resettable Thermal Protector
| Size | Supply | Speed (RPM) | Input Power (W) | Air Delivery (M3/hr) | Size (A) mm | Size (B) mm |
|---|---|---|---|---|---|---|
| 9" (225 mm) Fresh Air Heavy Duty | Single Phase, 50Hz | 1400 | 45 | 800 | 294 | 213 |
| 12" (300 mm) Fresh Air Heavy Duty | Single Phase, 50Hz | 1400 | 70 | 1600 | 395 | 305 |
| 9" (225 mm) Fresh Air Heavy Duty - MK II | Single Phase, 50Hz | 2300 | 70 | 1000 | 294 | 213 |
| 9" (225 mm) Fresh Air Heavy Duty - MK II | Single Phase, 50Hz | 1400 | 45 | 800 | 294 | 213 |
